WELCOME! CIVIL ENGINEERING

Laboratory

Name of Laboratory: Environmental Engineering - I (6CE07) & Environmental Engineering - II (7CE08)
Room No.: 315
Lab Area: 92 Sq.m
Capacity: 25
Lab In-Charge: Prof. Megha V. Neool
Lab Assistant: Mr. Nitin P. Shendre

List of Equipments/Items:
BOD Incubator, Muffle Furnace, Temperature calibrator, Digital Turbidity meter, Flocculator jar test apparatus, Magnetic Stirrer, Distillation Apparatus, Heatin mantle, Weight Balance, COD Apparatus, Inhoff Settling Cone, Ph meter, Choloroscope, DO Oxygen, Digital Conductivity Meter & Rispirable Dust Sampler.


Name of Laboratory: Research Lab
Room No.: 323
Lab Area: 70 Sq.m
Capacity: 10
Lab In-Charge: Prof. Rujit M. Puranik
Lab Assistant: Mr. Nitin P. Shendre

List of Equipments/Items:
5 Research PCs, Previous Year Thesis & Research References.


Name of Laboratory: Engineering Mechanics (1A3)
Room No.: 308
Lab Area: 147 Sq.m
Capacity: 25
Lab In-Charge: Prof. Sachit M. Vitankar
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Coil Friction Apparatus, Fletcher Trolley, Screw Jack Apparatus,Polygon Of Force Apparatus,Simple Jib Crane, Moment Of Inertia Of Flywood, Winch Crab Single Purchase, Winch Crab Double Purchase,Deflecting Beam Apparatus, Compound Pendulum, Simple Support Beam With Two Hook, Wooden Bar With Steel Plate, Parallel Forces Apparatus, Differential Wheel And Axel With Snatch Pulley Block, Cards And Hook, Combined Inclined Plane And Friction Slide Apparatus And Gear Train Apparatus


Name of Laboratory: Strength of Material (3CE06)
Room No.: 259
Lab Area: 74 Sq.m
Capacity: 25
Lab In-Charge: Prof. Pawan N. Wahane
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Rockwell Cum Brinell Hardness Tester, Pendulum Impact Testing Machine, Universal Testing Machine, Shear Test Attachment 5-20 Mm Dia., Shear Test Attachment 25-40 Mm Dia.


Name of Laboratory: Transportation Engineering (3CE07)
Room No.: 311
Lab Area: 97 Sq.m
Capacity: 30
Lab In-Charge: Prof. Bhavana S. Rathod
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Sieve Shaker Motorised, Oven With Range 105-110 Deg. Cen, Deval Attrition Testing Machine, Impact Testing Machine, Penetrometer, Tra Viscometer, Ring And Ball Apparatus, Ductility Testing Machine, Pensky Marten Apparatus, Crushing Value Testing MachineBitumen Container Kettle


Name of Laboratory: Engineering Geology (3CE09)
Room No.: 318
Lab Area: 66 Sq.m
Capacity: 30
Lab In-Charge: Prof. Megha V. Neool
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Mohs Scale Of Hardness, Mineral Set, Magnetic Compass, Rock Set, A Set Of Streak Plate, Geological Models, Clinometer And Hammer


Name of Laboratory: Geotechnical Engineering-I (4CE06) & Geotechnical Engineering-II (7CE07)
Room No.: 313
Lab Area: 81 Sq.m
Capacity: 25
Lab In-Charge: Prof. Sagar N. Kitey
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
GT-I: Pycnometer, Cylindrical Core Cutter Of Steel, Sieve Shaker Motorised, Liquid Limit Apparatus, Shrinkage Limit Test Apparatus, Compaction Cylindrical Metal Mould, Permeability Apparatus, Direct Shear Test Apparatus, Unconfined Compression Tester, Triaxial ApparatusGT-II: Standard Penetration Test Apparatus, Field Vane Shear Test Apparatus, Soil Resistivity Meter Model DDR3


Name of Laboratory: Survey-I (4CE08) & Survey-II (5CE09)
Room No.: 324
Lab Area: 106 Sq.m
Capacity: 25
Lab In-Charge: Prof. Nitin B. Kothari
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Optical Square, Distance Measuring Tape, Cross Staff, Wooden Peg, Line Ranger, Wooden Mallets, Plane Table, Prismatic Compass, Surveyors Compass, Survey Chains, Aluminum Levelling Staff-4m,Chaining Arrow, Plumb Bob, Theodolite, Dumpy Level, Distometer Imported Range 20m, Abney Level, Box Sextent, Tachometer Imported, Digital Plainmeter, Auto Level 24 X Terrano, Brass Alidade, Vernier Theodolite With Aluminium Stand, Mechanical Rebound Hammer, Safety Helmet (Yellow & White), Safety Jacket (Orange A & Green), Safety Gogals, Hammer And Misc Item


Name of Laboratory: Reinforced Cement Concrete (4CE09)
Room No.: 310
Lab Area: 97 Sq.m
Capacity: 25
Lab In-Charge: Prof. Nitin B. Kothari
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Compression Testing Machine Digital, Compaction Factor Apparatus, Slump Test Apparatus, Bulking Of Sand Apparatus, Vibration Machine, Vicat Apparatus, Le-chatelier Apparatus, Rebound Hammer Apparatus, Needle Apparatus.


Name of Laboratory: Building Planning & CAD (4CE07), Numerical Method and Computer Programming (6CE07)
Room No.: 319
Lab Area: 77 sq.m
Capacity: 30
Lab In-Charge: Prof. Rujit M. Puranik
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
DELL Optiplex 3040 Desktop, Hp Multifunction Plotter, Printer, UPS, Networking Rack, Jack Panel,Misc Accessories


Name of Laboratory: Theory of Structure (7CE06)
Room No.: 316
Lab Area: 92 Sq.m
Capacity: 30
Lab In-Charge: Prof. Saurabh A. Chavan
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Two Hinge Arc Apparatus, Maxwell Reciprocal Theorem Apparatus, Influence Line Diagram Apparatus, Truss And Frame Apparatus, Betty Theory Apparatus


Name of Laboratory: Fluid Mechanics-I (4CE07) & Fluid Mechanics-II (5CE07)
Room No.: 210 & 211
Lab Area: 136 Sq.m
Capacity: 25
Lab In-Charge: Prof. Bhavana S. Rathod
Lab Assistant: Nitin P. Shendre

List of Equipments/Items:
Tilting Flume Apparatus, Hot Wire Anemometer
